rear spring install help
#1
rear spring install help
As some of you may know, for the last three months or so, I've had coilovers in the front and stock springs in the back due to lca bolt problems. Well, today I managed to get my hands on replacement rear strut bolts and began to install my rear coilovers. Unfortunately, I've run into a very, very frustrating problem. The nut that is supposed to be spot-welded to the shock broke off and the head of the strut bolt broke off, meaning I have a bolt shaft holding my rear strut in place. Any ideas on how to get the damned thing out? I've tried hammering it for the last half hour or so... would drilling it out work?
#3
RE: rear spring install help
unfortunately, I don't have access to air tools... and I've been using a 3-lb mini sledge and a punch to hammer it... it hasn't really moved (maybe a few mm... not much at all)
#5
RE: rear spring install help
I'll see what I can do, but the only camera I have access to right now is my phone, so I'm not promising great photo quality
EDIT: ok... here's an idea... would I be able to just cut the bottom of the shock off? Like where the bolts go through. Because I have KYB AGX shocks to throw on, so I don't need the stock shocks anymore.
EDIT: ok... here's an idea... would I be able to just cut the bottom of the shock off? Like where the bolts go through. Because I have KYB AGX shocks to throw on, so I don't need the stock shocks anymore.
#7
RE: rear spring install help
ORIGINAL: reaper2022
EDIT: ok... here's an idea... would I be able to just cut the bottom of the shock off? Like where the bolts go through. Because I have KYB AGX shocks to throw on, so I don't need the stock shocks anymore.
EDIT: ok... here's an idea... would I be able to just cut the bottom of the shock off? Like where the bolts go through. Because I have KYB AGX shocks to throw on, so I don't need the stock shocks anymore.
#8
RE: rear spring install help
is that ur bushing(circled in red)?? i dunno any other way of getting that out other than strong air hammer or drill...cutting the shock fork wont do anything, the bolt is seized up in the bushing. theres a metal ring in the bushing that the bolt seizes too which is why this kinda thing always happens[&:]
[IMG]local://upfiles/4748/5CC5E83F06F84BF9BDAED376E21BA944.jpg[/IMG]
[IMG]local://upfiles/4748/5CC5E83F06F84BF9BDAED376E21BA944.jpg[/IMG]
#9
RE: rear spring install help
yeah it is... and civicex... have any advice for getting it out of the bushing? Because I pretty much need to have my car driveable by monday or else I have to find some other way to get to work.
edit: wait... so you think drilling it out will work? Because if that's the case, I can definitely do that... but with a 3" long or so bolt, it might take some time lol
edit: wait... so you think drilling it out will work? Because if that's the case, I can definitely do that... but with a 3" long or so bolt, it might take some time lol
#10
RE: rear spring install help
OH.... AJ, you're right, that is the metal collar of the bushing. I couldn't tell what was going on in that picture
Your bushing is junk now... you will need a new bushing, or a whole new control arm. If the metal sleeve got pushed that far out, the rubber is totally shot
Your bushing is junk now... you will need a new bushing, or a whole new control arm. If the metal sleeve got pushed that far out, the rubber is totally shot
